Rad02 "Uno"....140 kg / 140 cv by Radical Ducati

Rad02 "Uno" TECHNICAL SCHEDULE

-RAD02 frame, front bracket and rear subframe in alluminium. Only the frame weights 4,1 kg.
- RAD02  Alluminium hand made swingarm.
- ITX alluminium forged wheels.
- Bodywork in carbon fiber (fuel tank, solo seat, mudguards and fairing).
- Ohlins rear schock and fork.
- Discacciati brake system: Rotors, radial calipers, radial pump, in the rear special 200mm rotor + down caliper system.
- Exhaust 2 in 1 54/60 Wolfman / Spark
-999’03 engine with lightened flywheel, EVR antihooping clutch and Ducati Corse Superstock special heads (ported, big valves special camshafts).
-Electricals: Aviacompositi carbon fiber rev counter, race wiring and EVR 3 programable ecu.
-EVR carbon fiber big airbox.

Rad02 Imola by Radical Ducati

Rad02 Imola - TECHNICAL SCHEDULE


- Rad02 Cromo Molibdeno Frame
- S2R single side swingarm
- Rad02 Alluminium rear subframe
- Rad ergaltriple bridge yoke
- Sp ergal clip ons
- Ergal Rad Mv type rear suspension height nrod
- 749S Showa front fork
- Discacciati Rotors
- Discacciati calipers
- Discacciaticlutch and brake radial pumps
- V Rod front light
- M900ie electrical wiring
- Aviacomposite dash board
- 900SS ie engine
- S4RS Marchesini wheels
- Rad02 Cafe Racer fuel tank and solo seat in glass fiber
- 2 WolfMan independent exhaust line
- Rad carbon fiber front and rear mudguard

Rad Happy 2012 !!

Sport 944 by Radical Ducati (2008)

Technical Schedule Sport 944 (2008)


- Base: Ducati ST2
- Modified Frame
- Rad Front bracket
- Rad Licence plate support
- Original modified yokes
- Rad ergal clip ons
- Discacciati radial brake and clutch pumps
- Original wheels
- S2R single side swingarm
- Repositioned original wiring
- Aviacompositi rev counter
- BMC pod air filter
- Hi/low led light
- Montesa rear light
- Rad blinkers
- Rad02 Montjuich glass fiber bodywork (solo seat, fuel tank and fairing)
- Rad race carbon fiber bellypan
- Rad carbon fiber front and rear mudguard
- Original footrest with Rizoma foot pegs
- Rad carbon fiber water radiator side panels
- Tuned engine (ported heads, blue printed, light flywheel)
- 2 in 1 Wolfman Exhaust System
- Spark megaphone.

Fotografía: Javier Fuentes

Making of : http://www.radicalducati.com/index.php?page=sport944
